Anti-Static Dust Filter Bag
Anti-Static Dust Filter Bag
Our Anti-Static Dust Filter Bags are designed to provide exceptional filtration performance while preventing electrostatic discharge. These bags feature a unique blend of polyester fibers and conductive threads that effectively dissipate static electricity, making them ideal for applications where flammable dusts or gases are present. With a weight of 500 g/m² and a thickness of 1.6 mm, they offer excellent dust cake release and long service life. The surface treatment of singeing and calendering ensures smooth operation and prevents dust penetration.
Product Advantages
Special blend of polyester and conductive fibers for static dissipation
Prevents electrostatic discharge in potentially explosive environments
Optimal air permeability (200-350 L/M²/S) for efficient operation
Surface treatment of singeing and calendering for smooth dust release
Material Properties
High-quality polyester fibers with embedded conductive threads
Uniform weight distribution for consistent performance
Good resistance to abrasion and moderate chemical environments
Designed for continuous operation at temperatures up to 120°C
Production Capacity
Daily Output: 1000 - 1500 units (custom specifications available)
Standard sizes from 120mm to 160mm diameter, other sizes upon request
Key Applications
Ideal for industries requiring reliable dust filtration with anti-static properties:
Explosive Dust Handling
Chemical Processing
Pharmaceutical
Wood Dust Collection
Product Specifications
Temperature Resistance
Continuous: ≤120°C; Instant: ≤140°C
Material
Polyester Filament Needle Felt with Conductive Threads
Weight
500 g/m²
Thickness
1.6 mm
Air Permeability
200-350 L/M²/S
Surface Treatment
Singeing, Calendaring
Technical Parameters
Core Specifications
| Product Name | Anti-Static Dust Filter Bag |
|---|---|
| Material | Polyester Filament Needle Felt with Conductive Threads |
| Weight (g/m²) | 500 |
| Thickness (mm) | 1.6 |
| Air Permeability | 200-350 L/M²/S |
| Surface Treatment | Singeing, Calendaring |
| Continuous Operating Temp. | ≤120°C |
| Instant High Temp. | ≤140°C |
Mechanical Characteristics
| Tensile Strength (N/5*20cm) | Warp: ≥1060 | Weft: ≥1150 |
|---|---|
| Elongation at Break (%) | Warp: <35 | Weft: <45 |
| Finish Treatment | Singeing, calendering |
Chemical Properties
| Acid Resistance | Good |
|---|---|
| Alkali Resistance | Moderate |
| Abrasion Resistance | Excellent |
| Hydrolysis Resistance | Moderate |
